1. Overview of steam flowmeter?
1. Overview LFX rotor type steam flowmeter is a specialized instrument for measuring the cumulative mass flow of steam, with two structural types: mechanical and intelligent.; Through the indicator dial (mechanical) or LCD display screen (intelligent) on-site display, the quality of all steam flowing through the meter can be accurately read, and pulse signals can also be output. It also has manual pressure compensation or automatic temperature compensation functions. Due to its simple structure, moderate price, and wide measurement range, this flowmeter is widely used in industries such as petroleum, chemical, textile, and heating that require steam flow measurement.
2. Working principle: When the measured steam flows through the flowmeter body, it is throttled by the orifice plate. Under the action of the front and rear pressure difference, a part of the steam enters the nozzle of the diversion pipe, and the jet formed by the nozzle pushes the upper end of the rotor shaft to rotate. There are two damping blades at the lower end of the rotor shaft that rotate in a damping chamber filled with damping fluid, so that the wing wheel can fully absorb the kinetic energy of the jet.
. When the rotational torque of the wing wheel is balanced or different from the damping torque, the rotational speed of the wing wheel is proportional to the mass flow rate of the measured steam flowing through the flowmeter. Through correction and division, the actual flow rate of accumulated steam is reflected by the indicator dial.III. Main Parameters and Performance Indicators
1. Measurement of saturated steam and slightly superheated steam (superheat ≤ 20 ℃)
3、 The maximum working temperature is 183 ℃ (02) and 240 ℃ (05; 08; 10);
4、 The ambient temperature is only required for intelligent devices, ranging from 0 ℃ to 55 ℃ (special orders are placed for temperatures exceeding this range). 5. The pressure range for use is 0.03-1.0 MPa (02) 0.05-1.6 MPa (05; 08; 10);
6、 Installation method: Horizontal installation
7. Density compensation method: Mechanical compensation is manual pressure compensation; Intelligent automatic temperature compensation. Table 1 Flow Range (LFX-02) Unit: kg/h Steam Pressure (old cluster sensitive pressure) Mp Split Nozzle No. 3 2 1 0.03 7.5~25 15~50 30~100 0.05 8~27 16~53 32~105 0.1 9~30 18~60 36~120 0.2 11~36 22~72 43~145 0.3 12~41 25~83 50~165 0.4 14~46 27~92 55~183 0.5 15~50 30~100 60~200 0.6 16~54 32~107 64~215 0.7 17~57 34~115 69~229 0.8 18~61 36~121 73~242 0.9 19~64 38~127 74~255 1.0 20~67 40~133 80~265 Table 2 nominal flow unit: kg/h steam pressure (gauge pressure) Mp nominal flow when various specifications of flow meters are assembled with orifice plates LFX-05 LFX-08 LFX-10 1 2 3 1 2 3 1 2 3 0.05 660 265 133 1325 660 265 2650 1325 660 0.1 750 300 150 1500 750 300 3000 1500 750 0.2 915 366 183 1830 915 366 3660 1830 915 0.3 1050 420 210 2100 1050 420 4200 2100 1050 0.4 1165 466 233 2330 1165 466 1600 2330 1165 0.5 1270 508 254 2540 1270 508 5080 2540 1270 0.6 1365 547 273 2730 1365 547 5470 2730 1365 0.7 1450 576 290 2900 1450 576 5760 2900 1450 0.8 1540 615 315 3150 1540 615
