1. Calculation formula for air supply volume flow rate: Orifice flowmeter

The core formula for calculating air supply volume flow rate using an orifice flowmeter is: $q_ {v}=C \ varepsilon A_ {0} \ sqrt {\ frac {2 \ Delta p} {\ rho} $, with the calculation result in cubic meters per second ($m ^ {3}/s $). one Formula parameter analysis

(1) $q_ {v} $(volume flow rate) represents the volume of fluid per unit time and is the final calculation result.

(2) $C $(outflow coefficient) is related to the orifice plate structure, Reynolds number, and pressure measurement method, and the value needs to be determined through experimental calibration or by referring to standard charts.

(3) When the fluid is a gas, it needs to be calculated or corrected according to the pressure ratio ($\ Delta p/p $), isentropic index, etc. (liquid $\ varepsilon=1 $).

(4) $A_ {0} $(opening area) is calculated by the opening diameter $d $of the orifice plate, with the formula $A_ {0}={\ pi d ^ {2}}/{4} $, in square meters.

(5) $\ Delta p $(pressure difference) is directly measured through a differential pressure gauge, and it is necessary to ensure that the measuring point position meets the standard fuel preparation (such as corner joint pressure, flange pressure).

(6) $\ rho $(fluid density) The gas density needs to be corrected according to the actual working conditions (such as $\ rho={\ rho_ {0} p T_ {0}/{(p_ {0} T)} $), and the liquid can be regarded as a constant value. two Calculation steps

(1) Determine the orifice plate parameter measurement or query aperture $d $, calculate $A_{0} $, and confirm that the installation meets the standards (such as the length requirements of the str

(2) Measure the pressure difference $\ Delta p $using a calibrated differential pressure gauge to obtain data, avoiding interference from pipeline vibration or fluid fluctuations.

(3) To obtain the density of $\ rho $gas, the real-time density needs to be calculated based on temperature and pressure. For liquids, refer to the physical properties manual for values.

(4) Determine the coefficients $C $and $\ varepsilon $by matching parameters according to standards (such as ISO 5167) or data sheets provided by orifice plate manufacturers.

(5) Substitute the formula to ensure unit consistency (such as using Pascal for $\ Delta p $and meters for $d $), and consider the range of systematic errors in the calculation results.

2. What is the proportional relationship between orifice plate differential pressure and flow rate? Orifice flowmeter attitude recognition belongs to a type of differential pressure flowmeter, which, like other differential pressure flowmeters, requires a transmitter for data measurement. The classification and respective characteristics are shown in the table below. Orifice flow meters can be widely used in industries such as petroleum, chemical, natural gas, metallurgy, power, and pharmaceuticals for continuous measurement of volumetric or mass flow rates of various liquids, gases, natural gas, and steam. But many people dont know how to calculate an orifice flowmeter. Today, I will discuss with you the calculation formula of an orifice flowmeter. Simply put, the differential pressure value needs to be square root output to correspond to the flow rate. In practical applications, calculations are usually cumbersome and rarely done by oneself. Th
