1. What are the flow meter products with similar accuracy to electromagnetic flow meters?
Flow meter products with similar accuracy to electromagnetic flow meters mainly include Coriolis mass flow meters, high-precision pipe section ultrasonic flow meters, and high-precision turbine flow meters.
1. Coriolis mass flow meters.
The accuracy range is ± 0.05% - ± 0.2%, and some high-end models can achieve an accuracy of ± 0.05%, which matches the conventional accuracy range of electromagnetic flow meters. 2. It can directly measure mass flow without being affected by factors such as temperature, pressure, density, viscosity, etc., and can also output density and temperature parameters at the same time, with a large range ratio. 3. Representative products include Emerson high-precision series and Xingao Technology XMC series (optional ± 0.05% accuracy). 4. It is suitable for trade handover of crude oil, finished oil, chemical raw materials, liquefied gases, as well as accurate proportioning and mass balance scenarios in scientific research. 5. The limitation is that large-diameter products have high cost and are sensitive to vibration and two-phase flow, requiring regular zero point testing. Calibration.2. High precision pipe section ultrasonic flowmeter 1 The accuracy range is ± 0.5% - ± 1.0%, which meets the conventional accuracy requirements of electromagnetic flow meters. 2. It has the characteristics of zero pressure loss and no moving parts, and can measure non-conductive liquids (such as oil), supporting bidirectional measurement. Lower.
III. High precision turbine flowmeter 1 The accuracy range is ± 0.5% - ± 1.0%, and some high-end models can reach ± 0.2%. The accuracy is comparable
_600x400.jpg)
2. Chinese manual for TDS-100P portable ultrasonic flowmeter: [1]
The core content of the Chinese manual for TDS-100P portable ultrasonic flowmeter is as follows:
1. Product Overview TDS-100P portable ultrasonic flowmeter is a high-precision, non-contact flow measurement instrument suitable for real-time monitoring of liquid flow in industrial pipelines. Its core advantages include non-invasive measurement: no need to cut off the pipeline or install sensors, it can be directly clamped on the outer wall of the pipeline to complete the measurement. Portable design: small size, light weight, supports rapid deployment and mobile measurement on site. High precision and stability: Adopting dual channel ultrasonic technology, it has strong anti-interference ability and measurement accuracy can reach ± 1%. Multi functional display: Built in LCD screen displays real-time parameters such as flow rate, flow velocity, and cumulative flow rate, supporting data storage and export.
2. Instructions for use Installation steps Selection of measurement points: Avoid interference areas such as pipeline bends and valves, and ensure that the length of the upstream and downstream straight pipe sections meets the requirements (usually more than 10 times the diameter of the pipeline).
. Clamp sensor: Install the sensor perpendicular to the pipeline axis, adjust the spacing according to the K value indicated in the manual, and fill the gap with coupling agent to enhance signal transmission. Connect the host: Connect the sensor to the host through a dedicated cable, automatically recognize the sensor
