1. How to adjust parameters of electromagnetic flowmeter

Parameter adjustment of electromagnetic flowmeter needs to be configured according to the model and working conditions of the instrument. The core operations include setting the first number of the instrument system, adjusting the range, and calibrating the signal output. 1. Basic parameter settings • Instrument coefficient (K coefficient): Input according to the original coefficient marked on the sensor nameplate, usually the number of pulses per liter (e.g. 1.0000 represents 1L=1 pulse) • Measurement range: Calculated according to the pipeline diameter and flow rate range, the flow rate range of industrial pipelines is generally set to 0.5-10m/s • Flow unit: can choose m ³/h, L/min, kg/h, etc. (mass flow rate requires additional input of medium density) 2 Medium parameter configuration • Conductivity threshold: usually set to 5 μ S/cm, below which an empty pipe alarm will be triggered • Density setting: When measuring mass flow, the current medium density value under the working condition needs to be input • Viscosity compensation: For high viscosity media, the viscosity compensation function needs to be enabled (dynamic viscosity value needs to be input) 3 Output signal calibration • 4-20mA output: - Zero calibration: adjust the output to 4mA in no flow state - Full range calibration: adjust the output to 20mA at rated flow rate • Pulse output: - Set the pulse equivalent (the flow value represented by each pulse) - Adjust the pulse width (usually set to 50-500ms) 4. Special function settings • Automatic air traffic detection: automatically reset the output when the pipeline is empty after being enabled • Flow direction judgment: forward/reverse flow d

1. Parameter modification requires the use of specialized configuration software or handheld programmer provided by the manufacturer. 2 After modifying the key parameters, on-site real flow calibration must be carried out to verify the accuracy Parameter modifications involving safety interlocks require prior approval of process changes In explosion-proof situations, it is prohibited to open the cover with electricity. The power must be cut off before operation (note: specific operation should be based on the equipment manual, and this article is written according to the current national standard requirements of GB/T 18659-2018 Electromagnetic Flowmeters in 2024)

2. Main technical parameters of high-voltage electromagnetic flowmeter

The main technical parameters of high-voltage electromagnetic flowmeter are as follows: Execution standard: According to JB/T000 electromagnetic flowmeter standard. Nominal diameter: The DN series includes options from 5mm to 1200mm, while the rubber lining series has options from 10mm to 2000mm. Special specifications can be customized. Accuracy level: Two options are available: 0.5 level and 1.0 level. Working temperature: chloroprene rubber lining: 20 ℃ to+60 ℃. Polyurethane lining: 20 ℃ to+90 ℃. PTFE lining: 30 ℃ to+180 ℃. Work pressure: DN10 to DN65: 2.5Mpa. DN80 to DN150

1.6Mpa. DN200 to DN1600

1.0Mpa. Measurement range: The corresponding flow velocity range is 0.5m/s to 10m/s, and the conductivity requirement is greater than 20 μ s/cm. Output signal and load resistance: 0-10mADC, 0-1000 Ω, f
