Lobed Impeller Flow Meter Working Principle: Positive Displacement Rotary Roots Design for High Viscosities

Quick Answer

A lobed impeller flow meter is a positive displacement meter that uses two synchronized rotors to capture and transfer a fixed volume of liquid per rotation. The rotary roots design suits high viscosity fluids up to 100,000 cP because the rotor pockets do not rely on high flow velocity to create a signal. Send your viscosity, pipe size, and flow range to Silver Automation Instruments for a direct model recommendation.

What Is a Lobed Impeller Flow Meter

This meter type belongs to the positive displacement family. Engineers often call it a roots flow meter or rotating lobe meter in the field. The internal structure uses two lobed rotors inside a sealed housing. The rotors turn without touching each other. Timing gears on the shaft keep the rotors synchronized. Every pocket between the rotor lobe and the housing carries a known volume from the inlet to the outlet.

This design is different from turbine or electromagnetic meters. It does not need conductive liquid. It does not need high velocity. The rotation itself is the measurement mechanism. A sensor counts rotor turns and transmits a pulse or 4-20 mA HART signal.

How the Positive Displacement Rotary Roots Design Works

Liquid enters the inlet port at operating pressure. The pressure differential pushes the first rotor to turn. External timing gears force the second rotor to move in the opposite direction. The rotors form a temporary seal against the housing and each other. A known volume gets trapped in the lobe chamber. That volume moves from the inlet side to the outlet side as the rotors rotate. The cycle repeats for every lobe pass.

The total flow equals the chamber volume multiplied by the number of rotations. This direct volume counting makes the meter accurate even at low flow rates. A pick-up sensor detects each rotor pass. The transmitter converts the frequency to a flow rate in L/h or kg/h. Temperature compensation is optional with a PT100 or integrated sensor.

Most engineers skip the theoretical part. The practical point is simple. The meter output tracks a fixed volume, not velocity. This is why accuracy stays stable from 1 cP to 50,000 cP and often up to 100,000 cP with special clearances.

Why High Viscosity Service Demands This Design

High viscosity fluids resist flow. They create laminar flow profiles in pipes. Velocity based meters lose signal when the liquid moves slowly near the pipe wall. Electromagnetic meters work only with conductive liquids. Ultrasonic meters can struggle with heavy fuel oil or molasses because acoustic coupling degrades. The lobed impeller flow meter does not care about the velocity profile. The fluid is mechanically moved through the rotor chambers.

Because the rotors capture a fixed volume, viscosity changes do not destroy accuracy. The leakage between the rotor and housing decreases when viscosity rises. Thicker fluids actually seal the clearance better. This improves low flow performance. A heavy fuel oil at 2,000 cP will produce a strong rotor rotation even at 10 L/h in a small DN15 meter. A turbine meter at that flow would barely move.

We have seen this on customer sites many times. A paint manufacturer in Southeast Asia tested a DN25 lobed impeller meter on alkyd resin at 3,800 cP. The meter held 0.36 percent repeatability on 1,500 kg batches for six months. They replaced a mass flow meter because the resin would coat the tubes and drift.

Typical Flow Ranges, Pipe Sizes, and Accuracy

Silver Automation Instruments supplies lobed impeller flow meters from DN15 to DN200. The flow range depends on viscosity, pressure drop, and rotor clearance. For light oils below 50 cP, a DN25 meter often handles 2 to 100 L/min. For 10,000 cP adhesive or silicone oil, the same meter may be limited to 1 to 30 L/min because higher flow creates too much pressure drop.

Accuracy is typically ±0.5 percent of rate for liquids above 30 cP. For low viscosity solvents below 5 cP, accuracy drops to ±1.0 percent of rate because internal slip becomes larger. Repeatability stays within ±0.1 percent in most applications. This repeatability is what batching and dosing customers care about. The meter does not need to be perfect if it repeats and you apply a meter factor.

Common outputs include pulse, 4-20 mA HART, and Modbus RTU. The housing can be cast iron, stainless steel, or aluminum with PPS rotors. For food oils, we provide stainless steel with tri-clamp connections. For marine heavy fuel oil, we supply cast iron with flange connections. Pressure ratings go up to 40 bar for standard designs. Tem

Application Examples We See in the Field

Rotary roots meters work in sugar syrup batching in the Middle East. A dairy processor in New Zealand measures lactose slurry at 400 cP with a DN50 sanitary meter. A marine fuel supplier in Singapore uses four DN80 meters on bunker fuel lines at 380 cSt. A chemical plant in Mexico doses urea formaldehyde resin into a reactor at 140 °C and 8 bar. These are real operating conditions, not lab setups.

For water and wastewater, this meter type is less common. Do not select a positive displacement meter for dirty raw sewage or abrasive slurry with hard solids. The rotor clearances are small. Solid particles larger than 100 microns can jam the lobes. Use a strainer upstream. A 60 mesh basket strainer is standard for 1 to 50 cP clean oils. A 40 mesh strainer is enough for heavy fuel oil. For food products with soft particles, use a wider clearance rotor design.

Because the meter is positive displacement, it creates a pressure drop. The drop is usually below 0.5 bar for a properly sized meter. Undersized meters can exceed 1.5 bar and waste pump energy. Send your normal flow range and viscosity for a pressure drop calculation.

Model Selection Checklist

Before you request a quotation, collect these data points. Liquid name and chemical composition. Viscosity in cP at operating temperature. Flow range in L/h or kg/h. Pipe size in DN. Process pressure in bar. Process temperature in °C. Connection type, flange, thread, or tri-clamp. Output signal and hazardous area approval such as ATEX Zone 1 or IECEx. This list saves time and avoids back and forth emails.

Most engineers skip this part and later find the meter was sized for a different viscosity. In practice, the viscosity at cold start often determines the rotor torque. If the liquid is 15,000 cP at 20 °C and 1,200 cP at 80 °C, we need to check both conditions. Starting a positive displacement meter with cold sticky fluid can stall the rotors. We may recommend heat tracing or a pressure bypass line.

Here is the thing. The lobed impeller flow meter price is not based on line size alone. Rotor material, bearing type, body material, and hazardous area certification affect the cost more than line size. A DN25 food grade model can cost more than a DN80 cast iron marine model. Request a detailed quotation with the exact operating data.

FAQ

Question 1. What is the minimum viscosity for a lobed impeller flow meter?
The meter can measure from 1 cP but accuracy below 5 cP drops to about ±1.0 percent of rate. For solvents and very light oils, consider a turbine meter or Coriolis mass flow meter. The positive displacement design really earns its place above 30 cP.

Question 2. Can I use a lobed impeller flow meter for non-conductive liquids?
Yes. This is a common reason to choose it over an electromagnetic meter. It handles paints, oils, resins, polymers, and hydrocarbons without electrical conductivity.

Question 3. What happens if solid particles enter the meter?
Particles larger than the rotor clearance can jam the meter and damage the lobes. Install a strainer upstream. The mesh size depends on particle size and rotor clearance. For most 1 to 50 cP oils use a 60 mesh strainer.

Question 4. What is the difference between oval gear and lobed impeller designs?
Both are positive displacement meters. Oval gear meters use two oval-shaped gears that mesh directly. Lobed impeller meters use non-contacting rotors with timing gears. The lobed design is often better for higher flow rates and lower pressure drop. Oval gear meters often handle lower flow rates at lower cost. See our oval gear flow meter for diesel if your flow is below 5 L/min.

Question 5. What signal outputs are available?
Pulse output is standard for local batching counters. 4-20 mA HART is standard for PLC and DCS integration. Modbus RTU is available for remote monitoring. ATEX Zone 1 and IECEx approvals are optional for hazardous areas.

Get a Quote for Your High Viscosity Application

Tell us your liquid, viscosity in cP, flow range in L/h or kg/h, pipe size in DN, operating pressure in bar, and temperature in °C. Our engineers will check pressure drop, rotor clearance, and material compatibility. Send the data to Silver Automation Instruments on WhatsApp +86-25-52155837 or call +86-25-68650347. You can also reach us on WeChat at +86 15365082610. We reply to technical questions within 12 hours for most Asia Pacific time zones.
