1. What is the flow meter with a scale on the glass tube on the pipeline?
The glass tube flow meter with a scale on the pipeline is a glass rotor flow meter. This is an intuitive flow meter based on the principle of constant pressure drop and variable area measurement. The core structure of the working principle is a vertical conical glass tube and a float that can move freely inside the tube. When the fluid flows from bottom to top, a pressure difference is generated between the upper and lower parts of the float, pushing it up. When the upward force and buoyancy exerted on the float reach equilibrium with its own gravity, the float becomes stable at a certain height. At this point, by reading the outer scale of the glass early core beam tube corresponding to the top of the float, the instantaneous flow rate value can be obtained.
2. Main features * Simple structure, low price, easy installation and use. *The reading is intuitive, allowing for direct observation of the fluid flow state and float position. *The pressure loss is relatively small. *Vertical installation is required, and the glass material is fragile and not resistant to high pressure and high temperature. *The measurement accuracy is relatively low, usually ranging from 1.0 to 2.5 levels, and it belongs to commonly used industrial instruments. It is widely used in industries such as chemical, petroleum, light industry, medicine, food, paper, etc. It is used to measure the flow rate of clean and transparent liquids or gases, especially in situations that require direct display or process monitoring. Another occasionally mentioned type is the "glass tube liquid level flowmeter", which is more based on the principle of connectors and estimate
_600x400.jpg)
2. Glass rotor flowmeter AKB-6WB 0~60ml/min 2.5 level
Glass rotor flowmeter AKB-6WB (0~60ml/min, 2.5 level) is a cost-effective measuring instrument suitable for small flow clean media.
. 1. Product Core Information: The model of this flowmeter is AKB-6WB, with a measurement range of 0 to 60 milliliters per minute (ml/min) and an accuracy level of 2.5. It is based on the principle that the float rises and falls in a conical glass tube as the flow rate changes. It has a simple structure and intuitive readings. 2. Precision interpretation accuracy of 2.5 level means that its maximum allowable error is ± 2.5% of the full-scale value (60ml/min). Therefore, at any measurement point, the actual error will not exceed ± 1.5ml/min. This accuracy level is suitable for situations that require flow control but are not extremely demanding. It is usually used in laboratories, small production lines, or scientific research to measure and monitor the small flow of clean liquids (such as chemical reagents, water) or gases, such as in sample analysis, reagent addition, or small gas systems.3. Explanation of LZB-80 Glass Rotary Flow Meter
Explanation of LZB-80 Glass Rotary Flow Meter LZB-80 Glass Rotary Flow Meter is a flow measurement instrument with high sensitivity, wide measurement range, low pressure loss, and easy use and maintenance. The following is a detailed explanation of the flowmeter:
1. Selection of flow range: The selection of flow range determines t
