1. Installation skills for vortex flowmeter, which company will install this?

1. Vortex buried street flowmeter can only measure unidirectionally. When installing, pay attention to ensuring that the direction of medium flow is consistent with the direction indicated by the flowmeter arrow

2. The best installation method for vortex street flowmeter is vertical installation, where the medium passes through the flowmeter from bottom to top.

. Install the flowmeter on a vertical pipeline with a flow direction from bottom to top. Xian Hongpei Measurement and Control Instrument specializes in the production and installation of various flow meters. When installing horizontally, the flow meter must be installed in the high-pressure area of the entire system and ensure the corresponding outlet pressure; Do not install at the highest point of the pipeline, as the highest point often accumulates gas and the pipeline is not full. The outlet cannot be directly vented. When measuring high-temperature fluids, try to use a vertical installation method as much as possible; If horizontal installation is necessary, please install the transmitter part of the flowmeter vertically downwards or horizontally on the side to avoid excessive temperature; The injection and excavation fluid should only be installed in a location with good air flow or ventilation.

2. Installation requirements for straight pipe section of steam vortex flowmeter

The installation requirements for straight pipe section of steam vortex flowmeter are as follows: the basic installation direction and concentricity dispersion require the flowmeter to be installed horizontally on the pipeline, and the allowable pipeline inclination angle is

Installation diagram of vortex flowmeter
within 50 degrees.

. During installation, it is necessary to ensure that the axis of the flowmeter is completely concentric with the axis of the pipeline, and that the fluid flow direction is consistent with the direction indicated on the flowmeter. This reed stove requires avoiding measurement errors caused by installation tilt or eccentricity, ensuring stable fluid flow through the sensor detection area. Figure: Example of horizontal installation and straight pipe section configuration of steam vortex flowmeter. Standard length of upstream and downstream straight pipe sections. Upstream straight pipe section: An equal diameter straight pipe section with a diameter not less than 10 times the inner diameter of the pipeline (10D) needs to be configured. If the installation space allows, it is recommended to extend it to 20D to further eliminate the interference of complex flow states such as eddies and turbulence that may exist in the pipeline on the measurement. Downstream straight pipe section: An equal diameter straight pipe section with a diameter of not less than 5 times the inner diameter of the pipeline (5D) should be configured to ensure that the fluid can fully recover its stable state after passing through the flowmeter, and to avoid backflow caused by downstream equipment or bends affecting measurement accuracy. Note: D is the nominal diameter of the pipeline, and the straight pipe section should be completely consistent with the inner diameter of the flowmeter. The consistency of the inner diameter of the piping requires that the inner diameter of the upstream and downstream pipelines at the installation point of the flowmeter must be exactly the same as the nominal inner diameter of the flowmeter body. If
